Fluorescence Analysis Water Dissolved Oxygen Sensor Optical 12V Customized

  • 1
  • 2
  • 3

Brand Name : Desun Uniwill

Model Number : DS-380

Place of Origin : China

MOQ : 0~100 pcs

Price : $280.00 - $360.00/ Piece

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 0~1000 pcs

Delivery Time : 7~ 15 working days

Packaging Details : Carton packaging

Measuring range : 0~20mg/L

Response time : 3 seconds

Protection level : IP68

Power supply : DC 6~12V

product material : POM/SS316/Titanium

Power consumption : < 0.5 W

Calibration method : One or Two-point calibration

Accuracy : 1%

Maximum working pressure : 6bar

Fluorescent cap life : 1 year

Contact Now

Online Optical Dissolved Oxygen Transmitter For Water Treatment fluorescence analysis

This series of optical dissolved oxygen sensors measures the interaction between oxygen and certain luminescent dyes. It is designed to measure the concentration and saturation percentage of dissolved oxygen molecules (O2) in aqueous solutions.

Dissolved oxygen meter is a kind of online intelligent dissolved oxygen detector, we introduce foreign technology, adopt imported components and dissolved oxygen membrane head, based on the new polar spectrum analysis technology, and adopt advanced production process and surface mount technology.

The application of this series of advanced analysis technology ensures the stability, reliability and accuracy of the instrument for long-term use. It can be widely used for continuous monitoring of dissolved oxygen value in chemical industry, fertilizer, metallurgy, environmental protection, water treatment engineering, pharmaceutical, biochemical, food, aquaculture and tap water, etc.

Technical Parameters

Item Parameters
Model DS380
Principle Fluorescence analysis method
Measuring range 0~20mg/L or 0-200% saturation
Response time 3 sec
Accuracy 1%
Protection level IP68
Installation Submersible
Temperature sensor NTC
Temperature range 0~50°C
Temperature accuracy ±0.2°C
Output Support RS-485, MODBUS protocol
Power supply DC 6~12V, current <50mA
Size Φ26*155 mm
Probe cable length Default 5 m, customized 10m, 15 m and 30 m cable
Fluorescent cap life 1 year
Maximum working pressure 6bar
product material POM/SS316/Titanium alloy
Calibration method One or Two-point calibration
Power consumption < 0.5 W

Fluorescence Analysis Water Dissolved Oxygen Sensor Optical 12V Customized
